Dialogic DSI SIGTRAN Stack

DSI SIGTRAN Stack
Signaling Protocol Documentation and Downloads

Overview

Proven SIGTRAN protocol implementations for use within high performance products.

Use with the DSI SS7 Stack to build scalable systems for Prepaid, Roaming, SMS, USSD Services, Location Based Services etc.



Dialogic® DSI SIGTRAN Monitor delivers high-density protocol monitoring enabling applications to monitor SIGTRAN traffic between active signaling points and trigger intelligent actions.

The DSI Development Package available here now includes a set of Java classes providing functionality for use in a Java environment.



SIGTRAN Software

Product Description

SCTP

(Stream Control Transmission Protocol) IETF RFC4960, RFC3309

M2PA

(MTP2 User Peer-to-Peer Adaptation Layer) IETF RFC 4165

M3UA

(MTP3 User Adaptation Layer ASP and IPSP) IETF RFC 4666, RFC 3332

SUA

SUA (Signaling Connection Control Part User Adaptation) RFC 3868

SIGTRAN Monitor

Delivers high-performance, high-density protocol monitoring that enables applications to interrogate SIGTRAN traffic between active signaling points and trigger intelligent actions. SIGTRAN Monitor, a software only application, joins Dialogic® Network Interface Boards that have circuit-switched network monitoring capabilities.

Key Features

SIGTRAN Stack

APIs address complete message content to enable unrestricted service creation

Common API for SS7 and SIGTRAN protocols to aid migration of services from TDM to IP carrier networks, e.g. MTP3 to M3UA

DSI SIGTRAN Stack supported for Solaris, Linux, and Windows

SIGTRAN Monitor

Features

Benefits

Monitors user-selected types from M2PA, M3UA, and ISUP messages as well as those from specific network nodes

Minimizes the CPU and network load by capturing only those messages that pertain to the user application

Monitors multiple Ethernet ports simultaneously

A single software instance can monitor a high volume of traffic

Parses SCTP packets into discrete messages

Simplifies the user application by performing low-level, complex message decoding

Detects traffic congestion and defers sending monitored messages until congestion abates

Prevents monitoring from degrading the primary mission of the SIGTRAN service

Various capacities are available to meet network density and throughput demands

Matches capital expense to specific performance requirements

Resource Links

Product Datasheet
Signaling Protocol Documentation and Downloads
Global Product Approvals
DSI Software and Documentation for Signaling Servers
DSI Protocol Documentation and Development Packages

Documents

Find related manuals, data sheets, whitepapers, case studies and more. Click the icon to expand.

Application Notes

Developing Call Monitoring Applications Using Dialogic® SS7 Signaling and Media Products
This application note provides information about developing a call monitoring application using the Dialogic® SS7 signaling and media products. Dialogic developed a sample application that provides both a starting point and a reference for those who choose to develop an SS7-based application that monitors SS7 links and records calls on the links. Call recording can be triggered based on information related to the call. Calls may be recorded to multiple files or streamed through the data network for real-time monitoring.
USSD Services for Interactive Mobile Users
The application note describes the implementation of an interactive Unstructured Supplementary Service Data (USSD) service for GSM mobile users.  Sample code is included within the document.
Configuring an SS7 Demo System Using Dialogic® DSI Components with Dialogic® HMP Software Release 3.1LIN

This application note presents an SS7 demo system using Dialogic® DSI Components (SS7) with Dialogic® HMP Software Release 3.1LIN to demonstrate to users familiar with SS7 concepts that the SS7 configuration process can occur very quickly.
Enabling Dual-Chassis Fault Tolerance with the Dialogic® DSI SIGTRAN Stack
This application note describes how the DSI SIGTRAN Stack can be used to create a dual-resilient SIGTRAN M3UA-based platform that offers high availability and a high degree of fault tolerance.
Color Ring Back Tone — Building Feature-Rich Wireless Applications with Dialogic® Signaling Solutions
This application note describes the implementation of a Color Ring Back Tone (CRBT) wireless service. Focusing on the technologies and signaling involved, this document demonstrates how service providers can integrate CRBT into an existing Signaling System 7 (SS7) wireless application using Dialogic® Signaling Distributed Architecture (SigDiA) enabled building blocks.
Adding Location-Based Services to Existing Architectures
This application note provides an overall view of Location-Based Services (LBS), describes the signaling and technology involved, and discusses how Dialogic® signaling components can be used in implementing such services.

Brochures

Dialogic World Wide Services Brochure
Overview of the different services provided.

Case Studies

Enghouse Networks to Deliver Mobile Solutions with Dialogic Media Processing and Signaling Products

Enghouse Networks is known globally for offering software technology solutions for the planning, design, operation, and support of next-generation telecommunications and utility networks. For over fifteen years, Enghouse Networks and Dialogic have forged a relationship that spans multiple solutions deployed by over 80 customers in 70 countries with over a billion users – delivering unsurpassed mobile infrastructure solutions around the world. For this reason, Enghouse Networks trusted Dialogic components to help enable its next-generation Enghouse Networks-Jinny VAS in One (ViO) platform.

Whitepapers

Network Monitoring and Technology Challenges
This white paper presents a brief overview of network monitoring. It also discusses different network monitoring types and technologies: TDM (T1/E1, BRI, and analog), SS7 (monitoring within the service provider network), and session monitoring (IP and web).

Ordering Information

Use the Purchase page linked below to find partners to purchase Dialogic products. The order codes below are for your reference when making a purchase.

Where to Buy
ProductOrder CodeDescription
DSI SIGTRAN Stack

SS7SBHSTM2PAU

G09-005

M2PA Protocol Layer host license, 4 link eq, assoc

SS7SBHSTM2PAS

G10-005

M2PA Protocol Layer host license, 16 link eq, assoc

SS7SBHSTM2PAR

G11-005

M2PA Protocol Layer host license, 32 link eq, assoc

SS7SBHSTM2PAL

G12-005

M2PA Protocol Layer host license, 64 link eq, assoc

SS7SBHSTM2PAK

G13-005

M2PA Protocol Layer host license, 128 link eq, assoc

SS7SBHSTM2PAJ

G20-005

M2PA Protocol Layer host license, 256 link eq, assoc

SS7SBHSTM3UAU

G01-005

M3UA Protocol Layer host license, 4 link eq, assoc

SS7SBHSTM3UAS

887-243

M3UA Protocol Layer host license, 16 link eq, assoc

SS7SBHSTM3UAR

887-365

M3UA Protocol Layer host license, 32 link eq, assoc

SS7SBHSTM3UAL

887-242

M3UA Protocol Layer host license, 64 link eq, assoc

SS7SBHSTM3UAK

G15-005

M3UA Protocol Layer host license, 128 link eq, assoc

SS7SBHSTM3UAJ

G14-005

M3UA Protocol Layer host license, 256 link eq, assoc

SS7SBHSTSUAU

G08-005

SUA Protocol Layer host license, 4 link eq, assoc

SS7SBHSTSUAS

G07-005

SUA Protocol Layer host license, 16 link eq, assoc

SS7SBHSTSUAR

G06-005

SUA Protocol Layer host license, 32 link eq, assoc

SS7SBHSTSUAL

G05-005

SUA Protocol Layer host license, 64 link eq, assoc
DSI SIGTRAN Monitor

SS7SBHSTSMONS

G02-005

16 link eq/2 taps, 269KB/s

SS7SBHSTSMONR

G03-005

32 link eq/4 taps, 538KB/s

SS7SBHSTSMONL

G04-005

64 link eq/8 taps, 1076KB/s

SS7SBHSTSMONK

G19-005

128 Link/16 taps, 2152KB/s

SS7SBHSTSMONJ

G18-005

256 Link/32 taps, 4304KB/s

SS7SBHSTSMONH

G17-005

640 Link/64 taps, 10MB/s

SS7SBHSTSMONF

G16-005

1280 Link/64 taps, 20MB/s
