VolumeController

The VolumeController resource changes the output gain or volume of audio being played on a media stream or a conference.

XML Definition

<volumecontroller identifier="<identifier>" appid="<appid>"
    href=http://server/dialogicwebservice/mediacontrol/volumecontrollers/<identifier>
    streamidentifier="<stream identifier>"
    conferenceidentifier="<conference identifier>"
    level=”<level>” delta=”<delta>”>
</volumecontroller>

VolumeController Properties

Name

Description

Type

Input / Output

Optional / Mandatory

identifier

Unique identifier assigned to the specific instance of the resource. This identifier is used by the web service client when performing actions on the resource.

String

Output

N/A

appid

Unique application id included in the original HTTP POST creation process that is utilized by the web service such that clients only have access to resources that they created.

String

Output

N/A

href

An HTTP reference to the specific resource.

String

Output

N/A

streamidentifier

Unique identifier of the MediaStream that is to receive the media being played by the resource.

String

Input / Output

Mandatory
if conference
identifier is not being set

conferenceidentifier

Unique identifier of the Conference that is to receive the media being played by the resource.

String

Input / Output

Mandatory
if stream identifier is not being set

level

Sets the current gain level.

Values: {-12 ... 18}

String



Output

Optional

delta

Changes the gain relative to the current gain level.

String

Output

Optional



Interaction Diagram

VolumeController Creation

The following diagram illustrates the VolumeController creation process.


VolumeController Update

The following diagram illustrates the VolumeController update process.


VolumeController Deletion

The following diagram illustrates the VolumeController deletion process.


Java Sample Code

public void CreateVolumeController() {
      logger.info("VolumeController:: CreateVolumeController - Entered.");
      //Create a HttpURLConnection with the correct server
      //Send request to create an empty conference and retrieve response
      String requestBody = “<volumeController streamidentifier=\"1234567\"
              conferenceidentifier=\"23424244\" level=\”5\”
      </volumeController>”;

        HttpURLConnection connection = utils.SendHTTPRequest("http://" + MainSipServlet.IPMSHost +
           ":81/DialogicWebService/mediacontrol/volumeControllers", "POST", requestBody);
        if (connection != null) {
            xmlDoc = utils.GetHTTPXMLResponse(connection);
        }
        //Retrieve response codes
        int responseCode = 0;
        try {
            responseCode = connection.getResponseCode();
        } catch (IOException ex) {
            Logger.getLogger(MainSipServlet.class.getName()).log(Level.SEVERE, null, ex);
        }
        String responseMessage = "";
        try {
             responseMessage = connection.getResponseMessage();
        } catch (IOException ex) {
            Logger.getLogger(MainSipServlet.class.getName()).log(Level.SEVERE, null, ex);
        }
        String responseLocation = connection.getHeaderField("location");
        //close the connection
        connection.disconnect();
        //log results
        logger.info("VolumeController:: CreateVolumeController - Http response code =" +
             responseCode);
        logger.info("VolumeController:: CreateVolumeController - Http response message =" +
             responseMessage);
        logger.info("VolumeController:: CreateVolumeController - Http response location =" +
             responseLocation);
        if (responseCode == 201) {
            volumeControllerRef = responseLocation;
            identifier = ParseIdentifier();
        }
        logger.info("VolumeController:: CreateVolumeController - Exited.");
    }
